Medium And Low Voltage Aluminum Conductor Steel Reinforced Astm B232

Name: Medium And Low Voltage Aluminum Conductor Steel Reinforced Astm B232
Brand: Sanwu
Price: 1 USD

Brand Name : Sanwu

Model Number : ACSR-010

Certification : ISO CCC

Place of Origin : Henan

MOQ : 1000M

Price : Negotiable

Payment Terms : L/C, T/T, Western Union, MoneyGram

Supply Ability : 200 tons per day

Delivery Time : 1-15days

Packaging Details : New Wooden drum, reel, circle, or according to customers request.

Keywords : Aluminum Conductor Steel Reinforced

Original place : Henan, China

Life span : More than 30 years

Voltage : Medium And Low Voltage

Standard : ASTM B232

Conductor : Aluminum

Contact Now

Medium And Low Voltage Aluminum Conductor Steel Reinforced ASTM B232

The aluminum alloy and temper used for the outer strands in the United States and Canada is normally 1350-H19 and elsewhere is 1370-H19, each with 99.5+% aluminum content. The temper of the aluminum is defined by the aluminum version's suffix, which in the case of H19 is extra hard. To extend the service life of the steel strands used for the conductor core they are normally galvanized, or coated with another material to prevent corrosion. The diameters of the strands used for both the aluminum and steel strands vary for different ACSR conductors.

Acsr Dog Conductor Feature:

a. High tensile strength
b. Long life
c. Light in weight

Acsr Dog Conductor specification


Code	Size (AWG/MCM)	Number of Strands(mm)	Weight(kg/km)	Rated Strength(kg)
Rose	4	7*1.96	58.3	399
Iris	2	7*2.47	92.7	611
Pansy	1	7*2.78	117	740
Poppy	1/0	7*3.12	147.5	897
Aster	2/0	7*3.5	186	1375

Service Performance:
(1). The permissible long-time operating temperature for aerial conductors is 70℃.
(2). Under the circumstance that a rare climate is occurring and the ice coverage rate is low in heavy ice areas, the biggest stress of cable at the lowest point of the sag should not exceed 60% of the short-time destructive power.
(3). When connecting conductors, the conductor beside the connecting tube cant be prominent. Otherwise, the force on the operating conductors will be unbalanced. After connectors are install, the connecting tube should be painted by moisture-proof varnish in order to protect it from corrosion.
(4). Under installation, the arc downing stress of all the conductors should be the same. With in the permissible distance of crossing buildings or dropping to the ground, the stress can be 10-15% higher than regular stress.

Medium And Low Voltage Aluminum Conductor Steel Reinforced Astm B232

Product Tags:

Medium And Low Voltage Aluminum Conductor Steel Reinforced Astm B232 Images
